CDMA Band Selective Repeater 43dBm

GSM,CDMA,DCS,IDEN,TETRA,CDMA450M,WCDMA,GSM1900M Repeater full band / wide band / band selective / frequency selective / frequency shifting / fiber optical repeater *Remote control function *Software control through computer *Weather Proof Model numberGCOR43CSFrequency range825-835 MHz or 824-849 Mhz or Customer Specify870-880MHz or 869-894 Mhz or Customer SpecifyOutput power43dBmGainUL: 85dBDL: 90dBGain adjustable rangeMGC≥30Gain adjustable step1 dBGain control precision±1.5 dBPass band ripple≤±1.5dBNoise figure≤5dBI/O return loss≤-15 dBTransmission Delay≤1.5μSI/O impedance50Ω/N connectorSpurious emissionCarrier frequency Pass Band<-42dBc/30KHz(Δf≥750KHz) <-54dBc/30KHz(Δf≥1.98MHz)Pass BandΔf≥2.5MHz≤-22dBm/30KHzOut-bandΔf≥2.5MHz≤-36dBm/1KHz(9KHz—150KHz) ≤-36dBm/10KHz(150KHz—30MGHz) ≤-36dBm/100KHz(30MHz—1GGHz) ≤-30dBm/1MHz(1GHz—12.5GHz) ≤-67dBm/100KHz(806MHz—821MHz) ≤-67dBm/100KHz(885MHz—915MHz) ≤-67dBm/100KHz(930MHz—960MHz) ≤-67dBm/100KHz(1.8GHz—1.93GHz) ≤-67dBm/100KHz(3.4GHz—3.53GHz)Intermodulation attenuationIn work band≤-15dBm/30KHzOut work bandΔf≥2.5MHz≤-36dBm/30KHz(9KHz—1GHz)≤-30dBm/30KHz(1GHz—12.5GHz)Guard band rejection≤40dB or -13dBm/30KHz Δf≥2.5MHz≤60dB or -33dBm/30KHz Δf≥10MHzAmbient temperature-15°C-55°CAmbient humidity≤95% (no dew)Power supplyAC230V±10% 45-55HzReliabilityTo the GB6993-86 standardElectromagnetic compatibilityTo the ETS300 694-4 standardPanel displayLED display, Power, uplink, downlink emission, and alarm indicators
