GSM Band Selective Repeater 30dBm
Clive Chen
Contact person
Basic Information
| Place of Origin | Guangdong China (Mainland) |
|---|---|
| Brand Name | Gainer |
| Model Number | GCPR-G30S |
*GSM,CDMA,DCS,IDEN,TETRA,CDMA450M,WCDMA,UMTS,GSM1800M,UMTS repeater *High gain, easy installation and operation. *Use ALC and AGC technology, adjust extent automatically. *LED Light Working & Signal Condition Indicators. *Dependability stand by GB6993-86 standard. *Compatibility of electromagnetism according with ETS300 609-4. *cell phone repeater, mobile phone repeater. SpecificationUplinkDownlinkModel NumberGCPR-G30SOut Power30dBmMaximum Gain≥75dB≥80dBFrequency890-915Mhz(as per required)935-960 Mhz(as per required)Automatic Level Control≥20dBGain Flatness≤3dB(p-p)Manual Gain Control31dB in step of 1dBOut of Band Gain±400KHz< 50dB±600KHz< 40dB±1MHz< 35dB±5MHz< 25dBIntermodulation Products9KHz 1GHz≤ -36dBm≤ -20dBm1GHz 12.75GHz≤ -30dBm≤ -20dBmSpurious Emission9KHz 1GHz≤ -36dBm≤ -36dBm1GHz 12.75GHz≤ -30dBm≤ -30dBmNoise Figure at Max gain, 25ºC (typical)≤6dB @GmaxSWR≤1.8Group Delay≤ 4.5μsPower SupplyDC 9V/ 3AMechanical specificationDimensions(H*W*D)60*210*280mmWeight5KGI/O Connector / ImpedanceN-female / (Nominal)50ΩEnvironmental specificationIP RatingIP30Operating Temperature-10 50°CMonitoring specificationAlarmspecificationLED indicationPower LEDDC ON/OFFAlarm LEDALC1 5dB,orangeALC20 25dB,red
Delivery terms and packaging
Packaging Detail: Packing in resistant paper cartons suitale for long distance shipping. Delivery Detail: 8-10 working days
Port: Shenzhen
