GSM1800 Cell Phone Repeater 10dBm
Clive Chen
Contact person
Basic Information
| Place of Origin | Guangdong China (Mainland) |
|---|---|
| Brand Name | Gainer |
| Model Number | GCPR-D10 |
*High gain, easy installation and operation. *Use ALC and AGC technology, adjust extent automatically. *LED Light Working & Signal Condition Indicators. *Dependability stand by GB6993-86 standard. *Compatibility of electromagnetism according with ETS300 609-4. *cell phone repeater, mobile phone repeater. GSM,CDMA,DCS,IDEN,TETRA,CDMA450M,WCDMA Booster/Repeater GSM1800Cell Phone Repeater 10dBm SpecificationUplinkDownlinkModel NumberGCPR-D10Output Power10dBmMaximum Gain≥55dB≥55dBFrequency1710-1785 Mhz1805-1880 MhzAutomatic Level Control≥20dBIntermodulation Products9KHz 1GHz≤ -36dBm≤ -20dBm1GHz 12.75GHz≤ -30dBm≤ -20dBmSpurious Emission9KHz 1GHz≤ -36dBm≤ -36dBm1GHz 12.75GHz≤ -30dBm≤ -30dBmNoise Figure at Max gain, 25ºC (typical)≤5dB @GmaxSWR≤2.0Group Delay≤ 4.5μsPower SupplyDC 9V/ 3AMechanical specificationDimensions(H*W*D)23mm*145mm*175mmWeight1.5KGI/O Connector / ImpedanceN-female / (Nominal)50ΩEnvironmental specificationIP RatingIP30Operating Temperature-10 50°CMonitoring specificationAlarmspecificationLED indicationPower LEDDC ON/OFFAlarm LEDALC1 5dB,orangeALC20 25dB,red
Delivery terms and packaging
Packaging Detail: Packing in resistant paper cartons suitale for long distance shipping. Delivery Detail: 5-8 working days
Port: Shenzhen
